Build Them Right

Using our Quick-Connect® style fittings with automatic-locking jaws and our bulk cable you can build your assemblies in the field. The cable end is simply inserted into the fitting and the spring-loaded one-way jaws grab and lock on. If necessary, a reusable release tool can be used to disengage and remove or readjust the fitting.

CableRail fittings fixed end tension adjustment

Bulk Cable



All fittings and cables are manufactured from high-quality 316-grade stainless steel for weather-tough durability, ultra-low maintenance, and lasting beauty.



Bulk Cable – 1/8″ diameter 1×19 cable construction is available in various lengths for use with CableRail fittings.



Lengths:



Length Part #
100-ft #5100
250-ft #5250
500-ft #5500
Quick-Connect® Fittings
quick connect lag

Quick-Connect® Lag

9905DL-PKG



Fixed end fitting that screws into the face of a post or wall using the included hanger bolt with lag thread. Includes 2-in bolt for wood posts and 2 ½-in bolt for wrapped or composite-sleeved wood posts.

quick connect lag tensioner

Quick-Connect® Lag Tensioner

9910DL-PKG



Lag fitting with a special swiveling body that allows 3/4-in of take up for cable tensioning. Includes same hanger bolts as Lag fixed end fitting.

quick connect pivot

Quick-Connect® Pivot



9915DL-PKG



Fixed end fitting that screws into the face of a post or wall using the included hanger bolt with lag thread. 180º pivot range allows for angled stair terminations. Includes 2-in bolt for wood posts and 2 ½-in bolt for wrapped or composite-sleeved wood posts.

quick connect pivot tensioner

Quick-Connect® Pivot Tensioner



9916DL-PKG





Pivot fitting with a special swiveling body that allows 3/4-in of take up for cable tensioning. Includes same hanger bolts as Pivot fitting.

fittings and bulk cable for metal frames quick connect surface mount

Quick-Connect® Surface Mount

9903DL-PKG



Fixed end fitting that attaches to the face of a post or wall with the included screws or bolts. 130° pivot range allows for angled stair terminations. Includes 2-in lag screws for wood posts (½-in bolts for metal posts sold separately).

fittings and bulk cable for wood frames quick connect surface mount tensioner

Quick-Connect®

Surface Mount Tensioner

9913DL-PKG



Surface Mount fitting with a special swiveling body that allows 3/4-in of take up for cable tensioning. Includes same hanger bolts as Surface Mount fitting.

Image to reference

Additional Components
Level Intermediate Pickets
Stair Intermediate Pickets (Square Aluminum)
Level Intermediate Pickets (Round Stainless Steel)
Stair Intermediate Pickets (Round Stainless Steel)
Protector Sleeves
Tools
Cable Cutters
Quick-Connect® Release Tool
Cable Lacing Needle
Tension Gauge
CableRail Tensioning Tool
Multi-Tool
Wrench Wheel
Hanger Bolt Installation Tool
Stainless Steel Cleaner Kit

Care and Maintenance



Feeney offers comprehensive care and maintenance documents categorized by material: one for stainless steel fittings and cables, and another for powder-coated aluminum products.



For best protection of CableRail, Feeney recommends using SteelRenewal™ and SteelProtect™, a stainless steel cleaner and protectant kit combo pack to help maintain your stainless steel surfaces.



Resources
Technical Documents
  • CableRail Quick-Connect® Fittings

    PDF
  • PDF
  • CableRail Post Drill Hole Charts

    HTML
  • HTML
  • CableRail Quick-Connect® Lag & Pivot Fittings in Composite-Sleeved Posts

    PDF
  • PDF
  • Stainless Steel Care & Maintenance

    PDF
  • PDF
