DesignRail® Sample Case contents

1. DesignRail® Standard Post



w/Round Holes in Black with Post Cap(6” sample)



2. Commercial Post



w/Stair Slots (29°-34°) in Blue Steel



3. DesignRail® Heavy Duty Post



w/Round Holes in Textured Black (6” sample)



4. DesignRail® Single Corner Posts



w/Horizontal Slots in Coffee Cream (6” sample – loose insert) with Base Plate Cover in Black, plus Sample Case Info Card

5. Commercial Intermediate Stair Post Rail Adapter and Resin Panel Infills



Stair Post in Modern White(4”x4” samples):



A. Bear Grass Lite

B. Ginko Thatch

C. Connection Square Grey

D. Bamboo Rings

E. Ting Ting

F. Fossil Leaf

G. Rice Grass

H. Kathali Grays

I. Thatch 50%





design rail case samples

6. DesignRail® Standard Post



w/Stair Slots (29°-34°) in Dove Gray

7. DesignRail® Commercial Post



w/Round Holes in Oil Rubbed Bronze (6” sample)

8. DesignRail® Quick-Connect® Termination Post



in Iron Gray with sample of Quick-Connect® Inset fitting inside

9. RCBs (Rail Connecting Brackets) – 1″ Sample



Series 150 Top Rail and Panel Infill Bottom Rail and RCBs for all other Top Rails







10. Wall Adapter



24V 48W DC Wall Adapter in Black



11. DesignRail® Low-Profile Top Rail



Series 450 w/ Cedar Cap in Sparkling Champagne (6″ sample)





Graspable Series 250 Top Rail in Black with Drink Rail Adapter

12. DesignRail® Graspable Top Rail



Series 250 in Black with Drink Rail Adapter (6″ sample)







Series 200 in Walnut Wood Grain (6″ sample)

13. DesignRail® Rectangular Top Rail



Series 200 in Walnut Wood Grain (6″ sample)

14. DesignRail® Graspable Top Rail



Series 150 in Black (6″ sample)



15. LED Rail Light Strip



4″ strip with connectors







16. LED Post Accent Lights



in Bronze



17. Intermediate Picket for CableRail Infill



With holes, in Bronze (6″ sample)



18. Vertical Picket Infill



No holes, in Silver (6″ sample)

19. Stainless Steel Mesh Panel Infill



(6”x 6” samples):

A. Metropolitan™

B. Horizon™,

C. Dazzle™

D. Allure™.

Plus, Splice 90° and 45° Plates.

Case Update Instruction Sheet

20. Cable Samples



CableRail Kit – 1/8″ cable for metal.
Conceal Kit – 1/8″ cable

21. Accessory Case



A. Colored End Caps: Black, White, Brown, Gray, Silver, Taupe, Bronze, Green, Cream

B. CableRail Kit hardware and Quick-Connect® Release Tool

C. Conceal End Caps: Black, Bronze, Silver, White

D. Stainless Steel End Caps: Dome, Crown, Chamfer



22. Laser-cut Aluminum Infill Panel



Colors (6″ x 6″ samples)

(6”x 6” samples):



A. Sverra® – Silver

B. Cypher® – Textured Black

C. Pisces® – Bright White

D. Cubist® – Bronze

E. Bound® – Silver

F. Torrent® – Modern White

G. Seagrass® – Textured Black

H. Agama® – Matte Black

I. Trillium® – Bronze

PLUS: ColorEasy™ Fan Deck
